تعويض سوكت شحن سمسونج gt-s9001
samsung gt-I9001 Galaxy S Plus charging ways
pin1 = VBUS pin on C558 pin 2 = usb_DM at R527
pin 3 = usb_DP at R526
pin 4 = usb_ID at R525
pin 5 = ground
pin 6 = Vbat in TA502 and ZD500
caption: pin 1 position in the scheme is not clear sorry if its composition
inverted
see the picture below
pin1 = VBUS pin on C558 pin 2 = usb_DM at R527
pin 3 = usb_DP at R526
pin 4 = usb_ID at R525
pin 5 = ground
pin 6 = Vbat in TA502 and ZD500
caption: pin 1 position in the scheme is not clear sorry if its composition
inverted
see the picture below
